Honeywell Orbit MS7120 USB White


209,50 €
  • Varastostatus: Lähetetään 48 tunnissa
  • Toimitus alkaen: 8,50 €
  • Tuotenumero
  • 5010076971
  • Valm. tuotenro.
  • MK7120-71A38

Lyhyt kuvaus

Skannauselementin tyyppi
Näkyvä laser diodi

Tärkeimmät ominaisuudet

  • 20 scan line omnidirectional pattern
  • Sweet spot scanning
  • Adjustable scan head
  • Flash ROM
  • Automatic scanning operation


Metrologic's Orbit is an aggressive, omnidirectional presentation laser bar code scanner. Designed for applications where counter space is at a premium, Orbit is the ideal presentation scanner for retail, convenience, liquor and specialty stores. In addition, Orbit's unique, contoured shape allows it to be picked up and used as a hand-held when scanning large or bulky items. Lightweight and rugged, Orbit is small in size but big in performance.Engineered with a large, easy-to-find sweet spot, Orbit increases first pass read rate for maximum productivity. The scanning head can be tilted vertically a full 30° for added flexibility when scanning various sized objects. Orbit has a patented 20-line omnidirectional scan pattern that produces 1,200 scan lines per second. These features increase the scanning throughput, without increasing Orbit's size.Orbit is engineered for easy configuration and utilizes user-replaceable cables, in order to meet the multiple application needs across the many markets it serves. Data editing or "parsing" is also a standard feature. Parsing enables the encoded information to be manipulated to meet the host system's requirements.

Tekniset tiedot

Valmistaja Honeywell
Värikategoria Harmaa
Software Included MetroSet2, MetroSelect
Liitettävyystekniikka Langallinen
Skannauselementin tyyppi Näkyvä laser diodi
Koko tai muoto Pöytämalli
Skanneri Viivakoodiskanneri
Type Barcode scanner - desktop
Sisältyvät lisätarvikkeet
Sisältyvät kaapelit 1 x USB cable, USB-kaapeli, USB-kabel
Expansion / Connectivity
Interfaces 1 x USB
Compliant Standards
Compliant Standards CISPR 24, EN55022, ICES-003, EN55024, CISPR 22, FCC Part 15, RoHS, IEC 60950-1, EN 60950-1, IEC 60825-1, cULus, ISO 9001:2000, EN 60825-1
Alin käyttölämpötila 0 °C
Korkein käyttölämpötila 40 °C
Ilmankosteus käytössä 5 - 95% (non-condensing)
Operating temperature
Environmental Parameters / Drop Specification 1.2 m
Huolto & Tuki
Huolto ja tuki-lisätarvikkeet Limited warranty - 3 years
Service & Support
Service & Support 3 years warranty
Liitäntä USB
Barcode Reader
Barcode / Minimum Bar Width 5.2 mil
Barcode / Decode Capability Code 93, Code 39, RSS Code, Codabar, Code 128, UPC, Interleaved 2 of 5
Barcode / TTL Decoding Decoded
Barcode / OK Notification Beeper, LED indicator
Barcode / Pitch (Degrees) 60
Barcode / Skew (Degrees) 60
Mitat ja Paino
Leveys 10.2 cm
Syvyys 10.5 cm
Korkeus 15 cm
Paino 0.4 kg
